LIMAT-2-DN 2p AC C25/0.3

Order only Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	LIMAT-2-DN 2p AC C25/0.3
Brand	ETI
ETIM	EC000905
Rated current	25 A
Rated voltage	230 V
Release characteristic	C
Rated fault current	0.3 A
Leakage current type	AC
Degree of protection (IP)	IP20
Number of protected poles	2
Number of poles (total)	2

Packing details

Packing level 1	3838895462361, 3838895462361
Packing level 2	3838895462378, 3838895462378
Packing level 3	3838895462361, 3838895462361

Other Technical data

Built-in depth	68 mm
Current limiting class	3
Width in number of modular spacings	4
Frequency	50 Hz
Concurrently switching neutral conductor	Yes
Anti-nuisance tripping version	No

Description

RCBO, LIMAT-2-DN 2p AC C25/0.3, No. Of poles 2, Catalogue Group LIMAT2 DN Residual current circuit breakers with overcurrent protection, 8 moduls, Current type AC, Function RCBO, Overvoltage protection with overvoltage protection, Rated current (A) 25, Rated residual current (A) 0.3, Short circuit capacity (kA) 10, Tripping characteristic C
