LF06S-830-P LINFLEX SP-P 50W 24V8X1OSRAM
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | LF06S-830-P LINFLEX SP-P 50W 24V8X1OSRAM |
| Brand | OSRAM |
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| ETIM | EC002706 |
| Width | 11 mm |
| Beam angle | 120 ° |
| Length | 6000 mm |
| Height/depth | 3.7 mm |
| Lamp type | LED not exchangeable |
| Degree of protection (IP) | IP67 |
| Lamp power per meter | 8.3 W |
| Lamp voltage | 24 V |
| Colour temperature | 3000 K |
| Luminous flux per meter | 700 lm |
Other Technical data
| Mounting method | Surface mounting |
| Protection class | None |
| Model | Strip |
| Conductor cross section | 0.34 mm² |
| Connection type | Other |
| Voltage type | DC |
| Type of control gear | Not required |
| Diameter | 0 mm |
| Number of poles | 2 |
| With protective cover | Yes |
| Lowest bending radius | 50 mm |
| Length of particular segments | 50 mm |
| Number of nodes per meter | 120 |
| Max. system power | 0 W |
| Colour of light | White |
| Rated life time L70/B50 at 25 °C | 50000 h |
| Degree of protection (NEMA) | Other |
| Lamp power per foot | 2.5 W |
| Number of nodes per foot | 36 |
| Energy efficiency class of the built-in lamp | A++, A+, A (LED) |
| Power factor | 0 |
Description
CBP_02.00 Product family benefits, all [calc.]: Color consistency up to 2 SDCM on entire light strip thanks to Single-bin technology. Color rendering options Ra: 80 and 90. Service lifetime (L80/B10): up to 60,000 h. LM79 and LM80 compliant. Embedded constant current regulators. No solder-joints on circuit board. Type of protection: IP67 due to high performance silicon. Flexible and cuttable LED strips. CBP_03.00 Areas of applicat, all [calc.]: For high-end application with dedicated equipment and accessories. CBP_08.00 Equipment / Acces, all [calc.]: Flexessories: a complete set of aluminum channels with diffusers and lenses. Connectors: quick-and-easy toolless installation with SLIMCONNECTsystem G2.
