LF-DI10 LON
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
387,54 €
EAN: 4250184135692
MPN: 1108511319
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | LF-DI10 LON |
| Brand | METZ CONNECT |
| Categories |
Bus System Devices (KNX/Modbus)
|
| Country of origin | DE |
| Harmonized System Code | 8517 6200 00 |
| Bus system KNX | No |
| Bus system radio frequent | No |
| Bus system Powernet | No |
| With bus connection | Yes |
| Bus system LON | Yes |
| Bus system KNX radio | No |
| Radio frequent bidirectional | No |
Packing details
| Packing level 1 | 4250184135692, 4250184135692 |
Other Technical data
| Mounting method | DRA (DIN-rail adapter) |
| Number of inputs | 10 |
| Width in number of modular spacings | 2 |
| Type of voltage (input voltage) | AC/DC |
| External signal voltage necessary | No |
| Input voltage | 24 V |
| LED controlling | Yes |
| Degree of protection (IP) | IP20 |
| With LED indication | Yes |
| Bus module detachable | No |
| Min. depth of built-in installation box | 60 mm |
Description
The LON module with 10 digital inputs was developed for decentralized switching tasks. It is suitable for detecting potential-free switch states, for example electrical limit switches on vent valves or auxiliary contacts of power contactors. The inputs can be used as contact or voltage inputs and scanned individually or simultaneously by SNVT network variables. Suitable for decentralized mounting on DIN TH35 rail according to IEC 60715 in electrical distribution cabinets.Connection with screw type terminal blocks
