LED tube T8 Universal 1200mm 18W 840 for electronic and electromagnetic control gears
Order only
Price (excl. VAT):
15,79 €
Split box: 10,00 €
EAN: 4099854033162
MPN: 4099854033162
Package: 1
Box: 8
Estimate delivery time at our warehouse (approx.):
By request
Technical Information
| Item condition | New |
| Manufacture name | LED tube T8 Universal 1200mm 18W 840 for electronic and electromagnetic control gears |
| Brand | LEDVANCE |
| Categories |
T8 LED Tubes 18W
T8 LED Tubes 120cm G13 Light Bulbs |
| Country of origin | CN |
| Harmonized System Code | 8539 5200 00 |
| Energy Class | E |
| EPREL - European Product Registry for Energy Labelling | 1407622 |
| Socket | G13 |
| Colour rendering index CRI | 80-89 |
| Diameter | 27.8 mm |
| Lamp efficacy | 111 lm/W |
| Lamp shape | Tube, double-ended |
| Length | 1211 mm |
| Nominal voltage | 220 V |
| Type of cover | Frosted |
| Colour temperature | 4000 K |
| Lamp power | 18 W |
| Luminous flux | 2000 lm |
| Lamp designation | T8 |
| Filament lamp | No |
| Beam angle | 190 ° |
Packing details
| Packing level 1 | 4099854033162 |
| Packing level 2 | 4099854033179 |
| Packing level 3 | 4099854033162 |
Other Technical data
| Voltage type | AC |
| With remote control | No |
| Suitable for electronic ballast | Yes |
| Remote operation possible | No |
| Degree of protection (IP) | IP20 |
| Colour of light according to EN 12464-1 | Neutral white 3300-5300 K |
| Average nominal lifespan | 30000 h |
| Nominal current | 75 mA |
| Weighted energy consumption in 1000 hours | 18 kWh |
| IFTTT support available | Yes |
| Colour consistency (McAdam ellipse) | SDCM5 |
| Photobiological safety according to EN 62471 | RG0 |
| Min. number of switching cycles | 200000 |
| Rated luminous flux according to IEC 62612 | 2000 lm |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Suitable for magnetic ballast | Yes |
| Energy efficiency class according to EU regulation 2019/2015 | E |
| Power factor | 0.9 |
Downloads
Others
Product data sheet
Product data sheet for energy label
Instructions for use
Declaration DOC CE (Declaration of conformity CE)
Description
LED tubes for electronic control gear (ECG) and electromagnetic control gear (CCG). Product features: LED replacement for classic T8 fluorescent lamps with G13 socket for use in CCG luminaires and many common ECG luminaires (see compatibility list) or on AC mains. T8 LED tube made of glass with G13 base. Low flicker according to EU 2019-2020 (SVM ≤0,4 / PstLM ≤ 1). Mercury-free and RoHS compliant. Type of protection: IP20. Product benefits: High color homogeneity. Energy savings of up to 58 % (compared to T8 fluorescent lamp). Instant flickerfree starting. Areas of application: General illumination within ambient temperatures from -20…+45 °C. Corridors, stairways, parking garages. Domestic applications.
