LC 60W 24V SC SNC2 CV power supply unit LC
Order only
Price (excl. VAT):
45,45 €
EAN: 9006210799902
MPN: 87501051
Package: 1
Estimate delivery time at our warehouse (approx.):
2-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | LC 60W 24V SC SNC2 CV power supply unit LC |
| Brand | Tridonic |
| Categories |
LED drivers
|
| Width | 43 mm |
| Height | 30 mm |
| Length | 225 mm |
| Output voltage | 0 V |
| Output power | 18-60 W |
| Degree of protection (IP) | IP20 |
| Output current | 750-2500 mA |
| No dim function | Yes |
Packing details
| Packing level 1 | 9006210799902, 9006210799902 |
Other Technical data
| Suitable for outdoor use | No |
| Suitable for DC-voltage (primary side) | No |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | No |
| Dimming DMX | No |
| Dimming potentiometer (integrated) | No |
| Dimming GPRS | No |
| Dimming LineSwitch | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off | No |
| Dimming phase cut-on | No |
| Dimming programmable | No |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | No |
| Dimming DSI | No |
Description
Constant voltage LED driver ¦ Output voltage 24 V ¦ Max. output power 60 W ¦ Dimmable via external PWM LED dimmers attached on output side ¦ For luminaires of protection class I and protection class II ¦ The strain relief is included in both packaging variants. In the single packaging (SP) each Driver has also an individual packaging ¦ Nominal lifetime up to 50,000 h ¦ 5 years guarantee (conditions at www.tridonic.com) ¦ Cove lighting, facade accent lighting, ceiling integration, refrigerated displays ¦ 24 V, 60 W ¦ Small design (225 x 43 x 30.2 mm) with stretched-compact strain relief ¦ Very good THD performance in wide load range < 20 % ¦ Output LF voltage ripple (< 120 Hz) ± 1.5 % ¦ Power input on stand-by < 0.5 W ¦ Small cross section ¦ Push terminals for simple wiring ¦ Tridonic LLE-FLEX ADV G2 600, 1,200, 1,800 lm/m ¦ Tridonic LLE-FLEX EXC 600, 1,200, 1,800, 2,500 lm/m ¦ In connection with Flex accessories wire to PCB plug
