LED drivers
Order only
Price (excl. VAT):
32,55 €
EAN: 9006210778853
MPN: 28004042
Package: 1
Estimate delivery time to our warehouse: 2-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | LED drivers |
| Brand | Tridonic |
| Categories |
LED drivers
|
| Width | 43 mm |
| Height | 30 mm |
| Housing | Plastic housing |
| Length | 97 mm |
| Output voltage | 7.5-42 V |
| Output power | 2.25-28 W |
| Degree of protection (IP) | IP20 |
| Output current | 300-700 mA |
| Suitable for constant current | Yes |
| Suitable for constant voltage | No |
| No dim function | No |
Packing details
| Packing level 1 | 9006210778853, 9006210778853 |
Other Technical data
| Protection class | II |
| Model | Dynamic |
| Diameter | 52.43 mm |
| Suitable for outdoor use | No |
| Suitable for DC-voltage (primary side) | Yes |
| Constant light output (CLO) | Yes |
| IFTTT support available | No |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | Yes |
| Dimming DMX | No |
| Dimming potentiometer (integrated) | No |
| Dimming LineSwitch | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off | No |
| Dimming phase cut-on | No |
| Dimming programmable | Yes |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | Yes |
| Dimming DSI | No |
| Operation by Bluetooth | No |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Compatible with Casambi | No |
Description
NEW: lumDATA (DALI-2 part ext. 251, 252 and 253) ¦ Can be either used build-in or independent with clip-on strain-relief (see accessory) ¦ Dimming range 1 to 100 % (min. 5 mA) ¦ For luminaires of protection class I and protection class II ¦ Temperature protection as per EN 61347-2-13 C5e ¦ Adjustable output current between 300 – 700 mA via NFC or DALI ¦ Max. output power 28 W ¦ Up to 86 % efficiency ¦ Lowest power input on stand-by < 0.35 W ¦ Nominal lifetime up to 100,000 h ¦ 5 years guarantee (conditions at www.tridonic.com) ¦ Casing: polycarbonate, white ¦ Type of protection IP20 ¦ Near field communication (NFC) ¦ one4all (DALI-2 DT 6, switchDIM, corridorFUNCTION) ¦ Terminal blocks: 45° push terminals ¦ Adjustable output current in 1-mA-steps (NFC, DALI) ¦ Constant light output function (CLO) ¦ Protective features (overtemperature, short-circuit, overload, no-load) ¦ Suitable for emergency escape lighting systems acc. to EN 50172 ¦ Flexible configuration via companionSUITE (NFC, DALI) ¦ Application-oriented operating window for maximum compatibility ¦ Best energy savings due to low stand-by losses and high efficiency ¦ In-field programming possible after installation with NFC interface ¦ For downlight, spotlight and decorative applications
