LED drivers
Order only
Price (excl. VAT):
83,77 €
EAN: 9006210757230
MPN: 28003713
Package: 1
Estimate delivery time to our warehouse: 2-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | LED drivers |
| Brand | Tridonic |
| Categories |
LED drivers
|
| Width | 43 mm |
| Height | 30 mm |
| Housing | Plastic housing |
| Length | 97 mm |
| Output voltage | 7.5-42 V |
| Output power | 0.75-14 W |
| Degree of protection (IP) | IP20 |
| Output current | 100-400 mA |
| Suitable for constant current | Yes |
| Suitable for constant voltage | No |
| No dim function | No |
Packing details
| Packing level 1 | 9006210757230, 9006210757230 |
Other Technical data
| Protection class | II |
| Model | Dynamic |
| Diameter | 52.43 mm |
| Suitable for outdoor use | No |
| Suitable for DC-voltage (primary side) | Yes |
| Constant light output (CLO) | Yes |
| IFTTT support available | No |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | No |
| Dimming DMX | No |
| Dimming potentiometer (integrated) | No |
| Dimming LineSwitch | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off | No |
| Dimming phase cut-on | No |
| Dimming programmable | Yes |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | Yes |
| Dimming DSI | No |
| Operation by Bluetooth | Yes |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Compatible with Casambi | Yes |
Description
Can be integrated in Casambi systems (Casambi Ready) ¦ NEW: lumDATA (Luminaire data, Energy reporting and Diagnostics & Maintenance) ¦ Can be either used built-in or independent with clip-on strain-relief (see accessory) ¦ Forms automatically a wireless communication network with up to 250 nodes ¦ Dimming range 1 – 100 % (min. 6 mA) ¦ For luminaires of protection class I and protection class II ¦ Temperature protection as per EN 61347-2-13 C5e ¦ Adjustable output current between 100 – 400 mA via NFC ¦ Max. output power 14 W ¦ Up to 82 % efficiency ¦ Lowest power input on stand-by < 0.45 W ¦ Nominal lifetime up to 100,000 h ¦ 5 years guarantee (conditions at www.tridonic.com) ¦ Casing: polycarbonate, white ¦ Type of protection IP20 ¦ basicDIM Wireless ¦ Near field communication (NFC) ¦ Terminal blocks: 45° push terminals ¦ Adjustable output current in 1-mA-steps (NFC) ¦ Enhanced constant light output function (eCLO) ¦ Protective features (overtemperature, short-circuit, overload, no-load) ¦ Suitable for emergency escape lighting systems acc. to EN 50172 ¦ Flexible configuration via companionSUITE (NFC) ¦ Application-oriented operating window for maximum compatibility ¦ Best energy savings due to low stand-by losses and high efficiency ¦ In-field programming possible after installation with NFC interface ¦ For downlight, spotlight and decorative applications
