LED drivers
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | LED drivers |
| Brand | Tridonic |
| ETIM | EC002710 |
| Width | 51 mm |
| Height | 30 mm |
| Length | 102 mm |
| Output voltage | 0 V |
| Degree of protection (IP) | IP20 |
| Output current | 700 mA |
| No dim function | No |
Packing details
| Packing level 1 | 9006210552330, 9006210552330 |
Other Technical data
| Protection class | II |
| Suitable for outdoor use | No |
| Suitable for DC-voltage (primary side) | No |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | No |
| Dimming DMX | No |
| Dimming potentiometer (integrated) | No |
| Dimming GPRS | No |
| Dimming LineSwitch | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off | Yes |
| Dimming phase cut-on | Yes |
| Dimming programmable | No |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | No |
| Dimming DSI | No |
Description
Dimmable via leading edge and trailing edge phase dimmers ¦ Output dimmed analogue (current amplitude) ¦ Dimming range typ. 5 to 100 % (depending on dimmer) ¦ Potted style ¦ Type of protection IP20 ¦ Screw terminal ¦ Connecting cable, wire cross-section 0.5 – 2.5 mm² ¦ SELV ¦ 350, 500 or 700 mA output current ¦ Output power 14/15 W ¦ Nominal lifetime of 60,000 h (at max ta 50 °C with a failure rate ≤ 0.2 % per 1,000 h) ¦ 5 years guarantee (conditions at www.tridonic.com) ¦ Casing: polycarbonate, white ¦ Compact dimensions ¦ Overload protection ¦ Short-circuit protection
