ETHERLINE FD P Cat.5e 2x2x26/19AWG
Order only
Price (excl. VAT):
2,25 €
EAN: 4044773121025
MPN: 2170289
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | ETHERLINE FD P Cat.5e 2x2x26/19AWG |
| Brand | LAPP |
| Categories |
Ethernet cable (network)
|
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8544 4995 00 |
| Nominal cross section conductor | 2 mm² |
| Material core insulation | Polyolefin |
| Core identification | Colour |
| Stranding element | Pairs |
| Colour outer sheath | Blue |
| Category | 5E |
| Conductor material | Copper |
| Screen over stranding element | None |
| Screen over stranding | Foil + braiding |
| Material outer sheath | Polyurethane (PUR) |
| Conductor category | Class 6 = very flexible |
| Permitted cable outer temperature during assembling/handling | -5-0 °C |
| Permitted cable outer temperature after assembling without vibration | -30-80 °C |
| Number of cores | 2 |
| Halogen free according to IEC 60754-2 | No |
| Low smoke according to IEC 61034-2 | No |
| Outer diameter approx. | 5.9 mm |
| NVP value | 65 % |
| Conductor surface | Bare |
| Min. permitted bending radius, moving application with forced guidance | 93 mm |
| Min. permitted bending radius, moving application/free movement | 93 mm |
| Min. permitted bending radius, stationary application/permanent installation | 49.6 mm |
| Flame retardant according to IEC 60332-1-2 | No |
| Flame retardant according to IEC 60332-3-21 (Cat A F/R) | No |
| Flame retardant according to IEC 60332-3-22 (Cat A) | No |
| Flame retardant according to IEC 60332-3-23 (Cat B) | No |
| Flame retardant according to IEC 60332-3-24 (Cat C) | No |
| Flame retardant according to IEC 60332-3-25 (Cat D) | No |
| Halogen free according to IEC 60754-1 | No |
| Halogen free according to IEC 60754-3 | No |
Packing details
| Packing level 1 | 4044773121025, 4044774751108, 4044774751122, 4044774751139, 4044774751115 |
Downloads
Description
Voordelen; PUR-kabels: spanningsklasse 1000 V volgens UL - voor installatie naast voedingskabels EMC-afscherming Ononderbroken communicatie vanaf het sensor/actuatorniveau tot aan het internet Industrieel gebruik Voor gebruik in droge of vochtige ruimtes Toepassing; 2-paar: 10/100 Mbit/s voor Industrieel Ethernet Alleen voor patchkabeltoepassingen (max. 60 m) Kabelrupstoepassingen geschikt voor EtherCAT en EtherNet/IP-toepassingen 4-paar: 10/100/1000 Mbit/s voor Industrieel Ethernet
