UNIVERSAL BOX, configuration NA, Soundproofing
In stock
Minimal order quantity: 84
Price (excl. VAT):
0,77 €
per pcs
Subtotal: 64,68 €
MOQ: 84
EAN: 8595568929921
MPN: KPRL 64-60/LD_NA
Package: 1
Box: 84
Pallet: 3024
Estimate delivery time at our warehouse (approx.):
2-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | UNIVERSAL BOX, configuration NA, Soundproofing |
| Brand | KOPOS |
| Categories |
Flush Mounted Junction Boxes
|
| Country of origin | CZ |
| Harmonized System Code | 8536 3030 00 |
| Mounting method | Hollow wall |
| Model | Single |
| Shape | Round |
| Equipped with | None |
| Connectable | No |
| Provided with revolving ring | No |
Packing details
| Packing level 1 | 8595568929921 |
| Packing level 2 | 8595568929921 |
| Packing level 3 | 8595568929921 |
Other Technical data
| Colour | Yellow |
| Width | 0 mm |
| Halogen free | No |
| Diameter | 70 mm |
| Construction type | Device connection box (round/square) |
| Inner depth | 59 mm |
| Length | 0 mm |
| Sealable | No |
| Circuit integrity | None |
| Material | Plastic |
| Number of inlets | 14 |
| Mounting switching equipment | Screwing |
| For number of electric fittings | 1 |
| Luminaire hook mounting | No |
| Max. conductor cross section | 4 mm² |
| With screening | No |
| With nail lugs | No |
| With screws | Yes |
| Air tight | No |
| Depth | 60 mm |
| Suitable for cable diameter | 7-20 mm |
| For tube diameter | Other |
| Inlet from the rear | Yes |
| Pipe locking | No |
| Clamp position fixed | No |
| Number of poles of the clamp | 0 |
| Housing feed-through by seal membrane | No |
| Housing feed-through by nozzle | No |
| Housing feed-through by step membrane | No |
| Pipe locking optional | No |
| Number of included spouts | 0 |
| Housing feed-through by break-out opening | Yes |
| Transparent cover | No |
Downloads
Description
KPRL 64-60/LD - Box Universal wiringplasterboard., configuration NA, colour Ochre, package - 84 pcs - for installation of devices with a large mounting depth, the possibility of inserting the terminal plate, the mounting and the instrument screws are provided with a two-sided self-tapping thread for easier installation
