KB241.05 | Terminal strip 241.05SP-AK, 5-pole, 4 mm²
Order only
EAN: 6418677106361
MPN: KB241.05
Package: 1
Box: 1000
Pallet: 32000
Price (excl. VAT)
1,14 €
per unit
MOQ: 1
EDT to our warehouse: By request
This price is valid until next price list or while stock lasts
Technical Information
| Item condition | New |
| Manufacture name | KB241.05 | Terminal strip 241.05SP-AK, 5-pole, 4 mm² |
| Brand | Ensto |
| Categories |
Terminal Strips
|
| Harmonized System Code | 8536 9010 00 |
| ETIM | EC001284 |
| Rated voltage | 450 V |
| Drill hole distance centrically | 10 mm |
| Rated current In | 30 A |
| Explosion-tested version 'Ex e' | No |
Packing details
| Packing level 1 | 6418677106361 |
| Packing level 2 | 6418677106361 |
| Packing level 3 | 6418677106361 |
Other Technical data
| Mounting method | Direct mounting |
| Colour | White |
| Number of poles | 5 |
| Operating temperature | 80 °C |
| Number of clamp positions per pole | 2 |
| Inflammability class of insulation material according to with UL94 | V2 |
| Closing plate required | No |
| Type of electrical connection 1 | Screw connection |
| Type of electrical connection 2 | Screw connection |
| Transparent | Yes |
| Connectable conductor cross section fine-strand with cable end sleeve | 1.5-4 mm² |
| Connectable conductor cross section fine-strand without cable end sleeve | 1.5-4 mm² |
| Connectable conductor cross section multi-wired | 1.5-4 mm² |
| Material insulation body | Thermoplastic |
