IS-40/3-GV Eaton Moeller series IS Disconnector
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | IS-40/3-GV Eaton Moeller series IS Disconnector |
| Brand | EATON |
| Country of origin* | RO |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8536 5080 00 |
| ETIM | EC001545 |
| Voltage type | AC |
| Switching function | Other |
| Rated current | 40 A |
| Rated voltage | 415 V |
| Number of poles | 3 |
| Degree of protection (IP) | IP40 |
Packing details
| Packing level 1 | 9010238022607 |
| Packing level 2 | 9010238019850 |
Other Technical data
| With signal lamp | No |
| Built-in depth | 69.5 mm |
| Max. lamp power | 0 W |
| Lamp type | Other |
| Short-circuit breaking capacity (Icw) | 2 kA |
| Rated switching capacity | 0 kA |
| Width in number of modular spacings | 3 |
| Imprint/indication | Symbol "arrows" |
| Colour calotte | Other |
| Lamp socket | Other |
| Min. rated voltage | 240 V |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 0 |
| Number of contacts as change-over contact | 0 |
| Forced segregation according to DIN VDE 0113 | No |
Description
Switch-Disconnector with isolating function, type conform to IEC/EN 60947-3, jump activation, rated operating voltage 240/415V, rated insulation voltage 690V, rated impulse withstand voltage 6kV, standard front dimension 45 mm, terminal cross-section 2.5-50 mm², busbar compatible with xPole & xEffect circuit protection devices when using standard fork busbars, top-hat rail mounting
