INTERF.STAT. 24V DC

In stock: No Vendor stock: No Minimal order quantity: 1

Price (excl. VAT):

76,32 €

This price is valid until 24.12.25

EAN: 3389110651553

MPN: ABS2EC01EB

Box: 5

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	INTERF.STAT. 24V DC
Brand	Schneider Electric
Categories	Assembly Accessories and Parts
Country of origin	FR
Harmonized System Code	8536 4190 00
Mounting method	DIN rail
Function	Partially electronic
Rated current	0.05 A
Supply voltage	5-48 V

Packing details

Packing level 1

3389110651553

Other Technical data

Built-in depth	78 mm
Width in number of modular spacings	1
Control voltage 1	24 V
Control voltage 2	24 V
Type of control voltage 1	AC/DC
Type of control voltage 2	AC/DC
Voltage type of supply voltage	AC/DC
Max. switching current (cos phi = 0.6)	0.05 A
Max. incandescent lamp load	0 W
Max. load fluorescent lamp	0 VA
Max. load fluorescent lamp (Duo circuit)	0 VA
Max. load fluorescent lamp (parallel compensated)	0 VA
Number of contacts as normally closed contact	1
Number of contacts as normally open contact	0
Number of contacts as change-over contact	0

Description

This ABS2 input interface module is part of the range Zelio interfaces ABR/ABS. It is supplied in the form of slim module, 9.5 mm wide. It features a control circuit voltage of 24V DC. It is characterized by a high switching capacity and high durability. It is supplied with 1 NC contact and screw clamp terminals. Its protection index is IP20. It weighs 29g and its dimensions are, 9.5mm wide, 74mm high, 63mm deep. It is designed for interfacing discrete digital control signals exchanged within an automated system between the processing unit and the other components. It conforms to the most recent IEC 947-5-1 standards and is also UL and CSA certified. It is sold in lots of 5. It can be mounted on symmetrical, combination or asymmetricall DIN rail.
