Performance in Lighting

Insert+Zero Post 300 3.5 A/W 840 Gray

In stock: No Vendor stock: No Minimal order quantity: 1
Price (excl. VAT):
Price by request
This price is valid while stock lasts
EAN: 8018367734614
MPN: 3118129
Package: 1
Estimate delivery time at our warehouse (approx.): By request

Technical Information

Item condition New
Manufacture name Insert+Zero Post 300 3.5 A/W 840 Gray
Brand Performance in Lighting
Categories Street and park luminaires
Country of origin IT
Harmonized System Code 9405 4239 00
Width 53 mm
Colour rendering index CRI 80-89
Length 130 mm
Height/depth 305 mm
Lamp type LED exchangeable
Impact strength IK08
Nominal voltage 220 V
Degree of protection (IP) IP65
Beam angle Extreme wide beam >80°
Colour temperature 4000 K
Max. system power 4 W

Packing details

Packing level 1 8018367734614, 8018367734614

Other Technical data

Protection class I
Lamp holder Other
Conductor cross section 1.5 mm²
With base plate Yes
Connection type Other
Colour housing Grey
Surface protection Powder coating
Voltage type AC
With movement sensor No
Suitable for lamp power 4 W
Type of control gear Electronic ballast
With light sensor No
Number of poles 3
Housing material Aluminium
Type of luminaire Bollard luminaire
Light outlet Direct
Light sharing Asymmetric
Material cover Other
With light source Yes
Suitable for number of lamps 7
With control gear Yes
Nominal current 13
Colour of light White
IFTTT support available No
Type of wiring Ending
Light distributor Diffuser lens/optic/panel
Compatible with Apple HomeKit No
Compatible with Google Assistant No
Compatible with Amazon Alexa No
Max. number of luminaires per miniature circuit breaker C16 256
Max. number of luminaires per miniature circuit breaker B16 160
Colour temperature adjustable No
Luminous flux adjustable No
Beam angle adjustable No
Exchangeable control gear No
Housing material quality Other
Power factor 0.8

Downloads

Mounting instruction Product data sheet

Description

Mastarmatuur voor algemene verlichting buiten bestaande uit: Behuizing van spuitgietaluminium gelakt met polyester poederlak ISO 9227/12944 - ISO 9223 (C5). Afscherming van vlak van binnen gesatineerd glas. LED module voor netspanning 220-240V 50/60Hz beschermd tegen overbelasting tot 500 V. Pakking in slijtvast siliconen. Mast van gelakt geëxtrudeerd aluminium met flens. Snelle installatie met bevestigingsveren. De modellen zijn ontwikkeld zonder zichtbare schroeven.
