HIS-32/2 Eaton Distribution parts
Order only
Price (excl. VAT):
15,90 €
EAN: 4015081638512
MPN: 167351
Package: 1
Box: 60
Estimate delivery time at our warehouse (approx.):
8-10 weeks
Technical Information
| Item condition | New |
| Manufacture name | HIS-32/2 Eaton Distribution parts |
| Brand | EATON |
| Categories |
Main Switches
|
| Country of origin | RO |
| Harmonized System Code | 8536 5080 00 |
| Voltage type | AC |
| Switching function | Off switch |
| Rated current | 32 A |
| Rated voltage | 240 V |
| Number of poles | 2 |
| Degree of protection (IP) | IP20 |
Packing details
| Packing level 1 | 4015081638512 |
| Packing level 2 | 9008790471889 |
Other Technical data
| With signal lamp | No |
| Built-in depth | 69.5 mm |
| Max. lamp power | 0 W |
| Lamp type | Other |
| Short-circuit breaking capacity (Icw) | 2 kA |
| Rated switching capacity | 0 kA |
| Width in number of modular spacings | 2 |
| Imprint/indication | Symbol "arrows" |
| Colour calotte | Other |
| Lamp socket | Other |
| Min. rated voltage | 240 V |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 0 |
| Number of contacts as change-over contact | 0 |
| Forced segregation according to DIN VDE 0113 | No |
Description
Switch with isolating function, type conforms to IEC/EN 60947-3, the contacts' high wear resistance, jump activation, thumb-grip colour black, terminal cross-section 50 qmm, busbar compatible with protection switching devices when using the jaw clamp in combination with standard fork busbars
