HD90S C10/100 Residual Current Circuit Breaker with Overcurrent Protection 1+NP A type 100 mA
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | HD90S C10/100 Residual Current Circuit Breaker with Overcurrent Protection 1+NP A type 100 mA |
| Brand | ABB |
| Harmonized System Code | 8536 3010 00 |
| ETIM | EC000905 |
| Rated current | 10 A |
| Rated voltage | 230 V |
| Release characteristic | C |
| Rated fault current | 0.01 A |
| Leakage current type | A |
| Degree of protection (IP) | IP20 |
| Number of protected poles | 1 |
| Ambient temperature during operating | -25-55 °C |
| Number of poles (total) | 2 |
Packing details
| Packing level 1 | 5413656078357, 5413656078357 |
Other Technical data
| Voltage type | AC |
| Built-in depth | 35 mm |
| Rated insulation voltage Ui | 500 V |
| Current limiting class | 3 |
| Over voltage category | 3 |
| Pollution degree | 3 |
| Width in number of modular spacings | 2 |
| Frequency | 50 Hz |
| Concurrently switching neutral conductor | Yes |
| Rated short-circuit breaking capacity according to IEC 60947-2 | 10 kA |
| Connectable conductor cross section solid-core | 0.75-25 mm² |
| Connectable conductor cross section multi-wired | 0.75-16 mm² |
| With interlocking device | No |
| Flush-mounted installation | No |
| Anti-nuisance tripping version | No |
| Rated impulse withstand voltage Uimp | 6 kV |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 | 6 kA |
| Disconnection characteristic | Undelayed |
| Rated short-circuit breaking capacity according to EN 61009 | 10 kA |
Description
Fehlerstromschutzschalter: mit Überspannungsschutz (RCBO's). Eingesetzt zum Personenschutz und Schutz vor elektrischem Brandgefahren mit überspannungsschutz. Gemäß EN 61009-1. 10kA Fehlerstromschaltvermögen. Typ A. Erhöhter Personenschutz durch Ausführungen mit Bemessungsfehlerstrom von 100mA. Nennwerte 10A, 16A, 20A, 32A. Schaltstellunganzeige ON und OFF. B und C Charakteristik. Beschriftungsfenster ermöglichen ein eindeutiges Kennzeichnen der Stromkreise. Kann auch mit Hilfskontakten versehen werden.
