GYM+ 2 135 S/EW 840 WIT IK10
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
Price by request
EAN: 5414833112963
MPN: 3107127
Package: 1
Estimate delivery time at our warehouse (approx.):
By request
Technical Information
| Item condition | New |
| Manufacture name | GYM+ 2 135 S/EW 840 WIT IK10 |
| Brand | Performance in Lighting |
| Categories |
Wall and ceiling luminaires
Ceiling mounting lamps |
| Country of origin | FR |
| Harmonized System Code | 9405 1190 00 |
| Width | 292 mm |
| Colour housing | White |
| Colour rendering index CRI | 80-89 |
| Length | 1548 mm |
| Height/depth | 45 mm |
| Lamp type | LED not exchangeable |
| Impact strength | IK10 |
| Nominal voltage | 220 V |
| Beam angle | Extreme wide beam >80° |
| Colour temperature | 4000 K |
| Max. system power | 143 W |
Packing details
| Packing level 1 | 5414833112963, 5414833112963 |
Other Technical data
| Protection class | I |
| Lamp holder | Other |
| Conductor cross section | 2.5 mm² |
| Connection type | Other |
| Voltage type | AC/DC |
| With movement sensor | No |
| Suitable for lamp power | 143 W |
| Type of grid | White |
| Type of control gear | LED operating device current-controlled |
| With light sensor | No |
| Suitable for suspended mounting | Yes |
| Number of poles | 3 |
| Housing material | Steel |
| Suitable for light line configuration | No |
| Suitable for emergency lighting | No |
| Light outlet | Direct |
| Light sharing | Symmetric |
| Material cover | Plastic, opal |
| With light source | Yes |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 | No |
| Covering of the luminaire with thermally insulating material possible | No |
| Suitable for number of lamps | 1 |
| Suitable for built-in mounting | No |
| With control gear | Yes |
| Suitable for workplace according to EN 12464-1 | No |
| Suitable for surface mounting | No |
| Nominal current | 1000 mA |
| Colour of light | White |
| With air slots | No |
| Constant light output (CLO) | No |
| IFTTT support available | No |
| Type of wiring | Ending |
| Colour consistency (McAdam ellipse) | SDCM3 |
| Photobiological safety according to EN 62471 | RG1 |
| Rated ambient temperature according to IEC62722-2-1 | -40 °C |
| Filament test according to IEC 60695-2-11 | 650 °C - 30 s |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | No |
| Dimming DMX | No |
| Dimming potentiometer (integrated) | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off | No |
| Dimming phase cut-on | No |
| Dimming programmable | No |
| Dimming RF | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | No |
| Light distributor | Diffuser lens/optic/panel |
| Dimming DSI | No |
| Unified Glare Ratio (UGR) | 24 |
| Operation by Bluetooth | No |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Max. number of luminaires per miniature circuit breaker C16 | 54 |
| Max. number of luminaires per miniature circuit breaker B16 | 22 |
| Dimming DALI-2 | No |
| Colour temperature adjustable | No |
| Luminous flux adjustable | No |
| Beam angle adjustable | No |
| Exchangeable control gear | Yes |
| Suitable for ceiling mounting | Yes |
| Surface protection housing | Other |
| Power factor | 0.98 |
Downloads
Description
Opbouw armatuur voorzien van een witgelakt rooster, geschikt voor de verlichting van sportzalen, bestaande uit: Behuizing van gelakt staal. Optisch systeem met geïntegreerde prismatische verdeler uit PMMA met hoge lichttransmissie (>92%). Versterkte beschermingsrooster (IK10) met veiligheidssluiting. De versies DA zijn uitgerust met een dubbele ontsteking. De GYM+ 3 versie met dubbele schakelaar zorgt voor drie inschakelniveaus: alleen de middelste LED aan, de twee buitenste LEDs aan, of alle LEDs aan. Leverbaar zijn versies met ON-OFF driver en dimbare DALI driver. Plafondmontage of pendelmontage d.m.v. stalen ketting. Rotatie mogelijk d.m.v. draaiaccessoire.
