Fuse-link, high speed, 225 A, DC 1000 V, size 000, 24 x 36 x 115 mm, aR, IEC
In stock: No
Vendor stock: No
Minimal order quantity: 3
Price (excl. VAT):
139,94 €
Subtotal: 419,82 €
MOQ: 3
EAN: 5027590441872
MPN: 170M1812
Package: 1
Box: 3
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Fuse-link, high speed, 225 A, DC 1000 V, size 000, 24 x 36 x 115 mm, aR, IEC |
| Brand | EATON |
| Categories |
HRC Fuses
|
| Country of origin | CN |
| Harmonized System Code | 8536 1090 00 |
| Type of current | DC |
| Rated current | 225 A |
| Utilization category | aR (accompanied semiconductor protection) |
| Breaking capacity | 50 kA |
| Rated voltage DC | 1000 V |
| Fuse construction type according to IEC 60269 | 000 |
Packing details
| Packing level 1 | 5027590441872 |
| Packing level 2 | 5027590416658 |
| Packing level 3 | 5027590526753 |
Other Technical data
| Colour code | None |
| Type of fuse status indicator | None |
| Power loss at rated current | 45 W |
| Centre-to-centre distance of connections | 91 mm |
| Mounting holes | M8 |
Description
Fuse, Fuse-link, high speed, 225 A, AC 1000 V, size 000, 24 x 36 x 115 mm, aR, IEC, square body with offset bolted tags, semiconductor protection, IEC 60269-4
