| Item condition | New |
| Manufacture name | Photovoltaic Fuse Bussmann PV-A10F 10×38mm 15A 1000VDC gPV |
| Brand | EATON |
| Categories |
Cylindrical Fuses
|
| Country of origin* | IN |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8536 1050 00 |
| ETIM | EC002704 |
| Model | Ceramic fuse |
| Size | 10x38 mm |
| Voltage type | DC |
| Rated current | 15 A |
| Packing level 1 | 5027590505482 |
| Packing level 2 | 5027590263337 |
| Packing level 3 | 5027590365574 |
| Rated voltage | 1000 V |
| Release characteristic | Other |
| Utilization category | gPV (photovoltaic protection) |
| Type of fuse status indicator | Other |
| Breaking capacity | 50 kA |
| Rated operating frequency | 0 Hz |
| Power loss at rated current | 1.7 W |
Fuse, Fuse-link, high speed, 15 A, DC 1000 V, IEC 60269-6 type A, 10 x 38 mm, gPV, UL PV, UL, IEC, cylindrical, protection of solar PV strings, IEC 60269-6, UL 249-19, Breaking Capacity 50 kA, Optional accessories fuse holder CHPV1U
