FI switch 4P 40A 30mA A FLEX aside
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | FI switch 4P 40A 30mA A FLEX aside |
| Brand | EATON |
| Country of origin* | RO |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8538 9099 00 |
| ETIM | EC000003 |
| Voltage type | AC |
| Rated current | 40 A |
| Rated voltage | 0 V |
| Rated insulation voltage Ui | 440 V |
| Number of poles | 4 |
| Rated fault current | 0.03 A |
| Leakage current type | A |
| Selective protection | No |
| Short-circuit breaking capacity (Icw) | 10 kA |
| Surge current capacity | 0.25 kA |
| Short-time delayed tripping | No |
| Frequency | 50 Hz |
| Rated impulse withstand voltage Uimp | 4 kV |
Packing details
| Packing level 1 | 8711426743021 |
Other Technical data
| Mounting method | DIN rail |
| Built-in depth | 60 mm |
| Pollution degree | 2 |
| Width in number of modular spacings | 4 |
| Explosion-proof | No |
| Degree of protection (IP) | IP20 |
| Connectable conductor cross section solid-core | 1.5-35 mm² |
| Connectable conductor cross section multi-wired | 1.5-16 mm² |
| With interlocking device | No |
| Ambient temperature during operating | -25-60 °C |
| Additional equipment possible | Yes |
Description
4-pole residual-current circuit-breaker; 40 A; 30mA; class A; FLEX incl. connection cables on the side
