F9064B Eaton Moeller series Modular grid range (PREMERA MIX) - Wiring devices
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | F9064B Eaton Moeller series Modular grid range (PREMERA MIX) - Wiring devices |
| Brand | EATON |
| Country of origin* | CN |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8536 5080 00 |
| ETIM | EC000025 |
| Assembly arrangement | Modular device for domestic switching devices |
| Method of operation | Other |
| Frequency | 50 Hz |
| Type of load | Universal |
| Nominal voltage | 220-250 V |
| Suitable for degree of protection (IP) | IP20 |
| Device width | 25 mm |
| Device height | 50 mm |
| Device depth | 45 mm |
Packing details
| Packing level 1 | 5010826132057 |
| Packing level 2 | 9010238241954 |
Other Technical data
| Mounting method | Module frame |
| Colour | Black |
| Halogen free | Yes |
| Connection type | Screwed terminal |
| Surface protection | Untreated |
| Material quality | Duroplast |
| Material | Plastic |
| Type of fastening | Snapper mounting |
| Light value memory | Yes |
| Substation input | No |
| RAL-number (similar) | 0 |
| Serial dimmer | No |
| Applicable with movement sensor | No |
| Applicable with transmission button | No |
| Applicable with infrared button | No |
| Applicable with presence indicator | No |
| Applicable with button | Yes |
| Applicable with time switch/timer | No |
| Control voltage | 60-240 V |
| Transparent | No |
| Surface finishing | Matt |
| Core cross section | 1-2.5 mm² |
| Number of modules (module system) | 1 |
| IFTTT support available | No |
| Dimming phase cut-off | Yes |
| Dimming phase cut-on | No |
| Min. depth of built-in installation box | 28 mm |
| App control via Bluetooth | No |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
Description
Dimmer, Premera Mix, Black Insert, Power Modules, Amperage 60 - 250 W, Volts 200-250V~, No. of gang 1 Gang, 2 Way - Push on/off, BS EN 60669-2-1, IEC 60669-2-1, Black, Thermoplastic, Black, Thermoplastic, Grey, Thermoplastic, Front plate / module dimensions 50 x 25 mm, Recommended Minimum back box depth 28 mm, 0.054 kgs, Brass, Zinc Coated Steel with clear Passivation, Terminal capacity (L.N & E) 3 x 1.0mm², or 2 x 1.5mm², or 1 x 2.5mm² mm², Slotted Head, IP20
