ETITEC SIG EMH-TC 110 V 2GND

Order only Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	ETITEC SIG EMH-TC 110 V 2GND
Brand	ETI
ETIM	EC001466
Mounting method	DIN rail (top hat rail) 35 mm
Connection 1	Clamp
With remote signalling contact	No
Signalling at the device	Optic

Packing details

Packing level 1	3838895488651, 3838895488651
Packing level 2	3838895488668, 3838895488668
Packing level 3	3838895488651, 3838895488651

Other Technical data

Voltage protection level	450 V
Limiting frequency	10 MHz
Explosion-tested version	No
Nominal discharge surge current (8/20)	10 kA
Nominal load current	1 A
Nominal voltage DC	110 V
Max. continuous voltage DC	170 V
Pro-active thermo-control	No

Description

Surge arrester, ETITEC SIG EMH-TC 110 V 2GND, Catalogue Group ETITEC SIG Surge Arresters for signal/control lines, In (8/20) 10, No. Of poles 1, Function Surge protection of signal/control lines, Max. Discharge current Imax, 8/20 (kA) 20, Installation Home and residental building protection, Remote signalisation no, Type EMH-TC, Uc Continous Operating Voltage (V) 110/170 DC
