Wall and ceiling luminaire Altigo Lens Anthracite 20,50W 1650lm symmetric narrow (SE) IP65 IK05 3 SDCM 7112750

LED ceiling recessed luminaire for outdoor areas. For ceiling recessing. Cut-out opening x , Recess depth ≥ . As MLT version (Multi-Lens Technology), consisting of highly efficient UV and temperature-resistant lens systems in 4-fold configurations. With symmetric wide light intensity distribution. Flat cover of highly impact-resistant frosted PMMA. Luminaire luminous flux and light color fixed. Luminaire luminous flux 1650 lm, connected load 20,5 W, maximum luminous efficiency of luminaire 80 lm/W. Light colour neutral white, correlated colour temperature (CCT) 4000 K, general colour rendering index (CRI) Ra > 80. Colour locus tolerance (initial MacAdam) ≤ 3 SDCM. Further LED light colours available on request. Mean rated service life L80(tq 25 °C) = 50,000 h. Luminaire body of extruded aluminium profile and die-cast aluminium components. With flush-fitting cover and integral LED unit. Surface anthracite coated (DB 703). Dimensions (L x W): 1220 mm x 43 mm, luminaire height 32 mm. Safety class (EN 61140): III, protection rating (DIN EN 60529): IP65, impact resistance level in accordance with IEC 62262: IK05. Weight: 2,0 kg. The electrical connection to the separate control unit is made via the connecting cable leading to the outside (2000 mm). Luminaire without control unit. External ballast as accessory must be ordered separately. The control gear unit is replaceable in accordance with the ecodesign requirements (VO (EU) 2019/2020). Surge voltage resistance Differential Mode / Common Mode: / . The luminaire complies with the fundamental requirements of applicable EU regulations and product safety legislation and bears the CE symbol.
