Semi-complete Dali-dimmer
Ainult telli
Hind (ilma KM-ta):
96,24 €
EAN: 4011395316269
MPN: 2CKA006599A3047
Pakend: 1
Hinnanguline tarneaeg meie laos: 4-6 weeks
Technical Information
| Toote seisukord | Uus |
| Tootja nimi | Semi-complete Dali-dimmer |
| Bränd | ABB |
| Kategooriad |
Juhtimisseadmed lülitite ja pistikupesade jaoks
Lighting & Shutter Controllers |
| Päritoluriik* | DE |
| * Tegelik päritoluriik võib sõltuvalt tarn partiist erineda. Konkreetse päritoluriigi kinnitamiseks võtke palun ühendust oma kontohalduriga. | |
| Harmoneeritud süsteemi kood | 8536 5080 00 |
| Nimipinge | 230 V |
| Talitlusviis | Keeramis-/surunupp |
| Tunnusvool | 0.08 A |
| Sagedus | - Hz |
| Valgustatuse mälu | No |
| Alajaama sisend | No |
| Rakendatav koos liikumisanduriga | No |
| Rakendatav koos edastuslülitiga | No |
| Rakendatav koos infrapunalülitiga | No |
| Rakendatav koos olemasolu indikaatoriga | No |
| Rakendatav koos nupplülitiga | No |
| Rakendatav koos aeglüliti/taimeriga | No |
| Läbipaistev | No |
| Laius | 71 mm |
| Kõrgus | 71 mm |
| Seadme sügavus | 53.8 mm |
| Saadaval on rakenduste IFTTT sobitustugi | No |
| Reguleerimine, 1-10 V | No |
| Reguleerimine, DALI | No |
| Reguleerimine, tootja süsteemi | No |
| Reguleerimine, puutetundlik | No |
| Reguleerimine surunupuga | No |
| Reguleerimine, DSI (digital signal interface) | No |
| Sisseehitatud paigalduskarbi vähim sügavus | 28.5 mm |
| Operation by Bluetooth | No |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Metallic colour | No |
| Ühildub Casambiga | No |
Pakendamise üksikasjad
| Pakkimistase 1 | 4011395316269, 4011395316269 |
Kirjeldus
For DALI broadcast service (via central telegram). With integrated DALI power adaptor. For switching and dimming up to 64 DALI- devices like electronic ballasts and transformers with DALI-interface. With rotary control and ON/OFF push operation. For changing the colour temperature of >tunable white< lamps, which meet DALI Standard IEC 62386-209 (Device Type 8). Colour temperature can then be set between 2,700 K - 6,500 K. With electronic short-circuit protection. With electronic overload protection. Brightness power-on level and backround brightness level adjustable, buffered. With integrated LED illumination for orientation. Color of orientation light adjustable (18 presets and OFF). Up to 5 potentiometers are connectable in parallel. Up to 3 potentiometers are connectable in parallel in active mode. Not suitable for combining with other DALI sensors or central units of other manufacturers. DALI-voltage: 15,5 V= Rated current: max. 75 mA Power consumption: < 2,5 W Number of DALI-units: 37 in case of one active power-potentiometer in case of three active power-potentiometer in parallel connection: 111 Active mode: the potentiometer is supporting the necessary control circuit for other DALI-devices. Passive mode: the potentiometer is suitable as additional operation point. Max. DALI-cable length: 300 m (1,5 - 2,5 mm²). Without cover plate.
