EATON

Main switch, P3, 100 A, rear mounting, 3 pole, Emergency switching off function, With red rotary handle and yellow locking ring, Lockable in the 0 (Of

Ainult telli
Hind (ilma KM-ta):
110,96 €
Hind kehtib kuni 24.12.26
EAN: 4015081694020
MPN: 172818
Pakend: 1
Hinnanguline tarneaeg meie laos (umbes): 4-6 weeks

Technical Information

Toote seisukord Uus
Tootja nimi Main switch, P3, 100 A, rear mounting, 3 pole, Emergency switching off function, With red rotary handle and yellow locking ring, Lockable in the 0 (Of
Bränd EATON
Kategooriad Lülitite lahklülitid
Päritoluriik* GB
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmoneeritud süsteemi kood 8536 5080 00
Nominaalne püsivool Iu 100 A
Pooluste arv 3
Tunnus-talitluspinge 690 V
Kaitseaste (IP), esikülg IP65
Pealüliti variant Yes
Turvalüliti versioon No
Teenindus-/hoolduslüliti variant Yes
Nominaalne lühiajaline lühisvool LCW 2 kA

Pakendamise üksikasjad

Pakkimistase 1 4015081694020

Muud tehnilised andmed

Laius 95
Kõrgus 88
Sügavus 340
Tunnustalitlusvõimsus, AC-3, 400 V 37 kW
Normaalselt avatud abikontaktide arv 0
Normaalselt suletud abikontaktide arv 0
Arvutuslik tunnus-lühisvool Iq 80 kA
Ümberlülituvate abikontaktide arv 0
Lülitite arv 1
Blokeeritav Yes
Sisseehitatud mootorajam No
Peaahela ühendusviis Kruviühendus
Hädapeatamispaigaldise variant Yes
Juhtelemendi liik Ukse pöördajam
Tunnustalitlusvõimsus, AC-23, 400 V 55 kW
Juhtelemendi värvus Punane
Sobib pinnasele paigaldamiseks Yes
Sobib eest paigaldamiseks No
Sobib esiküljele paigaldamiseks No
Sobib paigaldamiseks jaotuskilbile No
Sobib vahepealseks paigaldamiseks Yes
Maksimaalne nimitööpinge Ue AC 690 V
Mootorajam, valikuline No
Valikuline pingevabasti No
Seadme ehitus Fikseeritud paigaldusega seade
Tunnus-pidevvool, AC-21, 400 V 100 A
Lülitusvõimsus pingel 400 V 55 kW
Ümberlüliti variant No
Tunnus-kestevvool talitluses AC-23, 400 V 100 A
Kaitseaste (NEMA) 12
Eelmonteeritud kaabeldusega No

Kirjeldus

Main switch, Product range: Main switch, maintenance switch, Part group reference: P3, Stop Function: Emergency switching off function, With red rotary handle and yellow locking ring, Notes: Handle only for use with extension shaft P1/P3-400 (172844)., Notes: With metal shaft for a control panel depth of 400 mm, Information about equipment supplied: Auxiliary contact or neutral conductor fitted by user., 3 pole, Locking facility: Lockable in the 0 (Off) position, Degree of Protection: Front IP65, Design: rear mounting, Motor rating AC-23A, 50 - 60 Hz 400 V: P = 55 kW, Rated uninterrupted current: Iu = 100 A , Standards: IEC/EN 60947, VDE 0660, IEC/EN 60204, Switch-disconnector according to IEC/EN 60947-3
