Printed circuit board terminals, 3.50 mm, Number of poles: 6, 90°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape image 1
Printed circuit board terminals, 3.50 mm, Number of poles: 6, 90°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape image 2
Printed circuit board terminals, 3.50 mm, Number of poles: 6, 90°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape image 3
Printed circuit board terminals, 3.50 mm, Number of poles: 6, 90°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape image 4
Printed circuit board terminals, 3.50 mm, Number of poles: 6, 90°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape thumbnail 1
Printed circuit board terminals, 3.50 mm, Number of poles: 6, 90°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape thumbnail 2
Printed circuit board terminals, 3.50 mm, Number of poles: 6, 90°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape thumbnail 3
Printed circuit board terminals, 3.50 mm, Number of poles: 6, 90°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape thumbnail 4
Weidmüller

PCB terminal, 3.50 mm, Number of poles: 6, Conductor outlet direction:

Ainult telli Minimaalne tellimuse kogus: 265
Hind (ilma KM-ta):
1,76 €
Hind kehtib kuni 24.12.25
Vahesumma: 466,40 € MOQ: 265
EAN: 4050118615104
MPN: 2604100000
Karp: 1
Hinnanguline tarneaeg meie laos (umbes): 4-6 weeks

Technical Information

Toote seisukord Uus
Tootja nimi Printed circuit board terminals, 3.50 mm, Number of poles: 6, 90°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape
Bränd Weidmüller
Kategooriad PCB Connectors & Terminals
Päritoluriik DE
Harmoneeritud süsteemi kood 8536 9010 00
Tunnuspinge 160 V
Tasandite arv 1
Tunnus-impulsspinge 2.5 kV
Kaitseaste (IP) paigaldatult IP20
Nurk, PCB/juhi ühendus 0°/180° (horisontaalne)
Tunnusvool In 17.5 A
Elektriühendusi 6

Pakendamise üksikasjad

Pakkimistase 1 4050118615104

Muud tehnilised andmed

Kõrgus 10 mm
Kere värvus Must
Talitlustemperatuur -50-120 °C
Kinnitusviis Jootetina
Isolatsioonimaterjali tulekindlusklass UL94 järgi V0
Liigpingekategooria II
Saasteaste 2
Juhi ühenduse tüüp Pistiku klamberühendus
PCB ühenduse tüüp THR-ühendus
Haru pikkus 1.5 mm
Materjali ühenduspind Tina
Mooduli eralduselementide ühendused 3.5 mm
Ribamärgistuse tüüp Muul viisil
Ühendatava juhi ristlõige, massiivsoonega 0.2-1.5 mm²
Ühendatava juhi ristlõige, peenekiuline koos kaabli otsamuhviga 0.25-1.5 mm²
Ühendatava juhi ristlõige, peenekiuline ilma kaabli otsamuhvita 0.2-1.5 mm²
Isolatsioonimaterjal Liquid crystal polymer
PCB kinnituse tüüp Muul viisil

Kirjeldus

LSF-SMT 3.50/06/90 1.5SN BK RL SO | Printed circuit board terminals, 3.50 mm, Number of poles: 6, 90°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape
