Floor-Standing Cabling Rack 42U W800D800 Fixed 19" Glazed Door R7035
Laos: Ei
Hankija laovaru: Ei
Minimaalne tellimuse kogus: 1
Hind (ilma KM-ta):
1 334,19 €
EAN: 3606480170713
MPN: NSYVDA42U88B
Pakend: 1
Kaubaalus: 1
Hinnanguline tarneaeg meie laos (umbes):
4-6 weeks
Technical Information
| Toote seisukord | Uus |
| Tootja nimi | Floor-Standing Cabling Rack 42U W800D800 Fixed 19" Glazed Door R7035 |
| Bränd | Schneider Electric |
| Kategooriad |
Cabinet Enclosures
|
| Päritoluriik | ES |
| Harmoneeritud süsteemi kood | 9403 2080 00 |
| Laius | 800 mm |
| Kõrgus | 2000 mm |
| Sügavus | 800 mm |
| Maksimaalne koormus | 400 kg |
| Seadmeraamide (RU) arv | 42 |
| Kaitseaste (IP) | IP20 |
| Mooduli eralduselement | 19 tolli |
| Kaitseaste (NEMA) | 1 |
Pakendamise üksikasjad
| Pakkimistase 1 | 3606480170713, 3606480170713 |
Muud tehnilised andmed
| Värvus | Hall |
| Mudel | Alalise raamiga |
| RAL-number | 7035 |
| Uste arv | 1 |
| Ventilatsiooni liik | Passiivne |
| Materjal | Teras |
| Pinna liik | Pulbervärvitud |
| Paigalduse tase | Esikülg |
| Profiilliistu tüüp | Puudub |
| Katuseplaadiga | Yes |
| Maandusega | No |
| Esiuksega | Yes |
| Küljeseinaga | Yes |
| Lahtimonteeritav | Yes |
Allalaadimised
Kirjeldus
This product is a floor standing enclosure designed for circulation applications with switches and routers. The enclosure dimensions are 42U, 800mm width and 800mm depth. The top and bottom frames are mechanically assembled by Torx screws to the vertical structure uprights, thus forming a rigid framework. Glazed reversible front door, 4 mm Securit glass, opening to 180°, 1-point lock with a key no. 333. Top and bottom side knock-out areas for cable entry and a large opening on the bottom and knock-out area on the rear for cable entry.
