EH3 DIN2 1125 AP Schrank DS
Laos: Ei
Hankija laovaru: Ei
Minimaalne tellimuse kogus: 1
Hind (ilma KM-ta):
2 072,20 €
EAN: 5411815239090
MPN: 4TBE843320C0100
Pakend: 1
Hinnanguline tarneaeg meie laos (umbes):
4-6 weeks
Technical Information
| Toote seisukord | Uus |
| Tootja nimi | EH3C93D1 EH3 DIN3 1125 AP cabinet DS |
| Bränd | ABB |
| Kategooriad |
Cabinet Enclosures
|
| Harmoneeritud süsteemi kood | 8538 1000 00 |
| Ahela terviklikkus | Puudub |
| Löögikindlus | IK10 |
| Kaitseaste (IP) | IP44 |
Pakendamise üksikasjad
| Pakkimistase 1 | 5411815239090 |
Muud tehnilised andmed
| Paigaldusviis | Paigaldamine põrandale |
| Kaitseklass | II |
| Värvus | Hall |
| Laius | 1445 mm |
| Kõrgus | 1125 mm |
| Sügavus | 320 mm |
| RAL-number | 7035 |
| Koos montaažiplaadiga | No |
| Pinnatöötlus | Töötlemata |
| Sisseehitussügavus | 0 mm |
| Ridade arv | 0 |
| Katte liik | Uks |
| Paigaldustoru sisendite arv | 0 |
| Laiendamine on võimalik | No |
| Sisemine sügavus | 0 mm |
| Kere materjal | Plast |
| Laius mooduli arvudes | 0 |
| Sobib väliskasutuseks | Yes |
| Moodulite arv | 0 |
| Ukse liik | Kahepoolne |
| Läbipaistev kate/uks | No |
| Lukuga | Yes |
| Sobib piksekaitseks | No |
| Tunnusvool (In) | 0 A |
| Kapi ümbrise paksus | 0 mm |
| Ukse või katteplaadi paksus | 0 mm |
| Katte kuju | Suletud |
| Ääreplaatide avade arv | 0 |
| Cover with overpressure release | No |
Allalaadimised
Kirjeldus
Cable distribution cabinet with profiled surface. They have a three-point lock with swivelling lever handle for 2 profile half cylinders. The cabinets are made of hot-pressed, glass-fibre reinforced polyester, dyed through in RAL 7035 light grey. They are corrosion-resistant and UV-resistant, making them suitable for outdoor use. The enclosures are suitable for ambient conditions from -35°C to +70°C. The open door can be easily disassembled by removing the hinge pins for optimal access to the cabinet. The door opening angle is greater than 180°. There are pressed-in core holes in the rear panel to accept M8 press-in nuts for mounting busbars, mounting frames or mounting plates. The enclosures are supplied with an open base, base plates are available as accessories. There are fixing points in the side panel for mounting horizontal busbars. The enclosures are designed for mounting on bases according to DIN 43629 with standard dimensions between the mounting points. EH3A80 Door AP profiled PK3/0 Single parts EH3
