Easy care Sanesca Multi-component Diffuser White rectangular ETDD 31W 4500lm asymmetric Wide (AW) IP40 IK06 3 SDCM

LED wall luminaire with indirect-direct light distribution. With night light function, diffuse light. For direct wall fixing. With asymmetric wide light distribution. Glare evaluation according to UGR rating (EN 12464-1) < 22. With translucent PMMA cover. Harmonious light effect due to homogeneously illuminated light emission. With 3 LED systems. Luminaire luminous flux 50 lm, connected load 5 W, maximum luminous efficiency of luminaire 145 lm/W. Light colour neutral white, correlated colour temperature (CCT) 4000 K, general colour rendering index (CRI) Ra > 80. Colour locus tolerance (initial MacAdam) ≤ 3 SDCM. Mean rated service life L80(tq 25 °C) = 70,000 h, mean rated service life L85(tq 25 °C) = 50,000 h. The light source is replaceable according to the ecodesign requirements (VO (EU) 2019/2020). Luminaire body of aluminium, Upper cover of sheet steel. Surface coated white (RAL 9016). Dimensions (L x W): 96 mm x 700 mm, luminaire height 190 mm. Permissible ambient temperature (ta): -20 °C - +25 °C. Safety class (EN 61140): I, protection rating (DIN EN 60529): IP40, impact resistance level in accordance with IEC 62262: IK06, testing temperature of wire glow test in accordance with IEC 60695-2-11: 650 °C. Weight: 4,5 kg. With two switchable electronic control units and one digitally dimmable (DALI) electronic control unit. Control gear unit according to DALI-2 standard (EN 62386). The control gear unit is replaceable in accordance with the ecodesign requirements (VO (EU) 2019/2020). The luminaire can be equipped with the Monitoring Ready (MOR) functionality on request. The luminaire complies with the fundamental requirements of applicable EU regulations and product safety legislation and bears the CE symbol. Luminaire available for 10 years, spare parts (LED module, control gear unit, optical system) for 15 years from date of invoice, subject to reasonable modifications in the interests of progress.
