EPC61N B40 Miniature Circuit Breaker - 1+NP - B - 40 A
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
18,76 €
per pcs
EAN: 5411815221255
MPN: 4TQA694284R0000
Package: 1
Box: 12
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | EPC61N B40 Miniature Circuit Breaker - 1+NP - B - 40 A |
| Brand | ABB |
| Categories |
Circuit breakers 40A
Breakers |
| Harmonized System Code | 8536 2010 00 |
| Rated current | 40 A |
| Rated voltage | 230 V |
| Release characteristic | B |
| Width in number of modular spacings | 1 |
| Number of poles (total) | 2 |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V | 6 kA |
Packing details
| Packing level 1 | 5411815221255 |
| Packing level 2 | 5411815221255 |
Other Technical data
| Voltage type | AC |
| Built-in depth | 44 mm |
| Frequency | 50-60 Hz |
| Rated insulation voltage Ui | 500 V |
| Current limiting class | 3 |
| Over voltage category | 3 |
| Pollution degree | 2 |
| Explosion-proof | No |
| Degree of protection (IP) | IP20 |
| Number of protected poles | 1 |
| Concurrently switching neutral conductor | Yes |
| Connectable conductor cross section solid-core | 0.75-16 mm² |
| Connectable conductor cross section multi-wired | 0.75-10 mm² |
| Ambient temperature during operating | 55 °C |
| Flush-mounted installation | No |
| Additional equipment possible | Yes |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V | 10 kA |
| Rated impulse withstand voltage Uimp | 6 kV |
Description
Unibis™ Leitungsschutzschalter der AEG Line sind eine der Neuerungen der ElfaPlus-Palette und wurden entwickelt, um die Größe des Platzbedarfs auf das absolute Minimum zu reduzieren. Brandneues Design 2P in 1 TE, 3&4P in 2 TE. 2 bis 32 A, B- und C-Charakteristik, 6 kA. 100% kompatibel mit allen ElfaPlus Anbauteilen und Zubehör. 100% Qualität und Verlässlichkeit bei nur 50% des Platzbedarfs.
