EPBMETER1 Eaton Memshield 3 MCCB Panelboard LV systems Panelboards
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | EPBMETER1 Eaton Memshield 3 MCCB Panelboard LV systems Panelboards |
| Brand | EATON |
| Country of origin* | IN |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8538 9099 00 |
| ETIM | EC002301 |
| Display | LCD |
| Accuracy class active energy according to IEC 62053-22 | 0.1S |
Packing details
| Packing level 1 | 4015081635795 |
Other Technical data
| Width | 99 mm |
| Height | 90.5 mm |
| Depth | 55 mm |
| Number of digital inputs | 1 |
| Number of digital outputs | 2 |
| Number of analogue inputs | 3 |
| Number of analogue outputs | 3 |
| Voltage type of supply voltage | AC |
| Supporting protocol for PROFIBUS | No |
| Supporting protocol for Modbus | Yes |
| Supporting protocol for other bus systems | Yes |
| Degree of protection (IP), front side | IP40 |
| Ethernet-connections | 0 |
| Ampere meter | No |
| Blind power meter | No |
| With rotational speed meter | No |
| Frequency meter | Yes |
| Pulse counter | Yes |
| Voltmeter | No |
| Effective power measurement device | Yes |
| Supporting protocol for PROFINET IO | No |
| Supply voltage AC 50 Hz | 100-240 V |
| Supply voltage AC 60 Hz | 415 V |
| Supply voltage DC | 0 V |
| Measuring range for frequency | 45-65 Hz |
| Display resolution (horizontal) | 0 px |
| Display resolution (vertical) | 0 px |
| Accuracy class reactive energy according to IEC 62053-23 | 0.1S |
| Sampling frequency | 19200 Hz |
| Number of voltage measurement inputs | 4 |
| Number of current measurement inputs | 3 |
| Supporting protocol for IEC 61850 Ethernet | Yes |
| Supporting protocol for OPC UA PubSub | Yes |
| With audit logging (audit log) | Yes |
| With firmware signature | No |
| With logging of security events (security event log) | Yes |
| With Role Based Access Control (RBAC) | No |
| Web server with HTTPS transfer protocol | No |
| Remote display | No |
Description
MEM 3, PB multifuntion metering device, MODBUS and PULSED output
