V-TEC PG11 SGR Cable gland, PG11, silver gray Polyamide
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
0,56 €
EAN: 4012195160816
MPN: 2022621
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | V-TEC PG11 SGR Cable gland, PG11, silver gray Polyamide |
| Brand | OBO Bettermann |
| Categories |
Standard Cable Glands
|
| Country of origin | HU |
| Harmonized System Code | 3926 9097 00 |
| Model | Straight |
| Thread length | 8 mm |
| Material quality | Polyamide (PA) |
| Thread type | PG |
| Material | Plastic |
| Hexagon angular dimension | 25 mm |
| Suitable for cable diameter | 3.5-10 mm |
| Degree of protection (IP) | IP68 |
| Nominal thread size metric/PG | 11 |
Other Technical data
| Colour | Grey |
| Halogen free | Yes |
| Shock resistant | No |
| RAL-number | 7001 |
| Surface protection | Untreated |
| Bend radius protection/trumpet flare | No |
| With strain relief | Yes |
| Glass-fibre reinforced | No |
| Type of sealing | Sealing ring |
| Operating temperature | -20-65 °C |
| Pitch thread | 1.41 mm |
| Explosion-tested version | No |
| Flat cable coupling | No |
| Multi seal area | No |
| With locknut | No |
| Separable screw gland | No |
| For Ex-zone gas | None |
| For Ex-Zone dust | None |
| Wrench width | 22 mm |
Description
V-TEC PG11 SGR Cable gland, PG11, silver gray Polyamide
