ETI

EFI-2 A 80/0.5

Order only Not Available
Estimate delivery time to our warehouse: By request

Technical Information

Item condition New
Manufacture name EFI-2 A 80/0.5
Brand ETI
ETIM EC000003
Rated current 80 A
Rated voltage 230 V
Number of poles 2
Rated fault current 0,5 A
Leakage current type A
Selective protection No
Short-circuit breaking capacity (Icw) 10 kA
Short-time delayed tripping No
Frequency 50 Hz

Packing details

Packing level 1 3838895027133, 3838895027133
Packing level 2 3838895276630, 3838895276630
Packing level 3 3838895027133, 3838895027133

Other Technical data

Built-in depth 69 mm
Width in number of modular spacings 2
Degree of protection (IP) IP20
Additional equipment possible No

Description

RCCB, EFI-2 A 80/0.5, No. Of poles 2, Catalogue Group EFI-2 A, AC A and AC type, Function RCCB, Rated current (A) 80, Rated residual current (A) 0,5, Rated voltage (V) 230, Type A
