Technical Information
Item condition |
New |
Manufacture name |
EB2 630/4LE 630A 4p |
Brand |
ETI
|
Categories |
Power Circuit Breakers
|
Rated permanent current Iu |
630 A |
Number of poles |
4 |
Degree of protection (IP) |
IP20 |
With switched-off indicator |
Yes |
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz |
36 kA |
Integrated earth fault protection |
No |
Device construction |
Built-in device fixed built-in technique |
Packing details
Packing level 1 |
3838895409984, 3838895409984, 3838895409984, 3838895409984 |
Packing level 2 |
3838895409984, 3838895409984 |
Other Technical data
Overload release current setting |
252-630 A |
Motor drive integrated |
No |
Type of electrical connection of main circuit |
Screw connection |
Type of control element |
Rocker lever |
Adjustment range short-term delayed short-circuit release |
630-5040 A |
Adjustment range undelayed short-circuit release |
3528-6300 A |
Suitable for DIN rail (top hat rail) mounting |
No |
Motor drive optional |
Yes |
DIN rail (top hat rail) mounting optional |
No |
Complete device with protection unit |
No |
Description
Molded Case Circuit Breaker, EB2 400/4LCD 400A 4p APCWH, No. Of poles 4
