E-DAT Industry RJ45 field plug insert Cat.5 Class D PROFINET
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | E-DAT Industry RJ45 field plug insert Cat.5 Class D PROFINET |
| Brand | METZ CONNECT |
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8536 6990 00 |
| ETIM | EC001121 |
| Model | Plug |
| Screened | Yes |
| Type of connector | RJ45 8(4) |
Packing details
| Packing level 1 | 4250184180333 |
| Packing level 2 | 4250184180333 |
Other Technical data
| Colour | Silver |
| Connection type | Insulation displacement connector |
| Category | 5 |
| Suitable for round cable | Yes |
| Suitable for flat cable | No |
| Suitable for litz wire conductor | Yes |
| Suitable for solid core | Yes |
| AWG-range | 2622 |
| Transparent | No |
| Special tool necessary | No |
| Compatible with Grade2TV according to XP-C 90-483 | No |
| Compatible with Grade3TV according to XP-C 90-483 | No |
Description
Cat.5 plug to be assembled in the field and mounted in IP67 plug housings of variants 1, 4, 5 and 14, 100 MBit suitable according to IEEE 802.3, suitable for Remote Powering (PoE, PoE plus and UPoE) and HDBaseT, 4-wire RJ45 plug for AWG 22 to be assembled in the field, connection of AWG 26/7 - 22/7, AWG 26/1 - 22/1 possible, solid copper wire diameter from 0.4 to 0.64 mm, stranded copper wire diameter from 0.48 to 0.76 mm, conductor diameter up to 1.6 mm, cable jacket from 5.5 to 8.5 mm, consists of only 2 parts, easy assembly - connection without special tools, zinc die-cast housing for industrial use, protected locking hook, can be used as test plug at IP67 end of variants 1, 4, 5, 6 and 14
