Drainage pump Unilift CC5 -A1 1x230V 50Hz 10m cable with plug
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
272,90 €
EAN: 5700830761366
MPN: 96280966
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Drainage pump Unilift CC5 -A1 1x230V 50Hz 10m cable with plug |
| Brand | GRUNDFOS |
| Categories |
Pump Systems & Units
|
| Country of origin | HU |
| Harmonized System Code | 8413 7021 00 |
| Nominal current | 0.98 A |
| Weight | 4.51 kg |
| Number of phases | 1 |
| Immersing depth | 2 m |
| Cable length | 5 m |
| Max. discharge flow | 6 m³/h |
| Max. static height | 5 m |
| Flange shape | Round |
| Rotational speed | 2850 1/min |
| Ambient temperature | 0 °C |
| Electrical connection | Connection cable with plug |
| Rated voltage | 220 V |
| Explosion-proof | No |
| Frequency | 50 Hz |
| Degree of protection (IP) | IP68 |
| Material impeller/pump wheel | Polypropylene (PP) |
| Material motor housing | Stainless steel |
| Material quality motor housing | Stainless steel 304 (1.4301) |
| Motor power input (P1) per motor | 0.25 kW |
| Motor power output (P2) per motor | 0.11 kW |
| Volume flow rate (BEP) | 2.56 m³/h |
| Discharge head at flow rate (BEP) | 24.51 kPa |
| Connection standard outlet side | ISO 7-1 / EN 10226-1 |
| Nominal operating mode | S3 |
| With protection against dry running | No |
| Motor speed control | None |
| Pump diameter | 160 mm |
| With cutting system | No |
| Material pump casing | Polypropylene (PP) |
| Pump height | 306.6 mm |
| Pump circuit | With external float |
| Insulation class according to IEC | B |
| Max. dimension of fixed parts | 10 mm |
| Material quality pump casing | PP-GF |
| Suitable for dry set-up | No |
| Medium temperature (continuous) | 0 °C |
| Material quality impeller/pump wheel | PP-GF |
| Nominal diameter connection outlet side | 1 1/4 inch (32) |
| Connection outlet side | External thread conical BSPT-R (ISO 7-1 / EN 10226-1) |
| Flange compression stage connection outlet side | Other |
Packing details
| Packing level 1 | 5700830761366, 5700830761366 |
Downloads
Description
Grundfos Unilift CC pumps are single-stage submersible pumps with a low suction ability down to 3 mm water level.
