Double push-button insrt two-way 1 pole, flush-mntd, 10 A, AC 250 V, screw term.
Order only
Not Available
Technical Information
| Item condition | New |
| Manufacture name | Double push-button insrt two-way 1 pole, flush-mntd, 10 A, AC 250 V, screw term. |
| Brand | Schneider Electric |
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| ETIM | EC000029 |
| Nominal voltage | 250 V |
| Method of operation | Rocker |
| Model | Series push button |
| Rated current | 10 A |
| Number of poles | 1 |
| With lighting | No |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 0 |
Packing details
| Packing level 1 | 3606480306846 |
| Packing level 2 | 3606480306843 |
| Packing level 3 | 3606480306844 |
Other Technical data
| Mounting method | Surface mounted (plaster) |
| Assembly arrangement | Basic element |
| Halogen free | Yes |
| Imprint | None |
| With signal lamp | No |
| Label space/information surface | No |
| Feedback-signal contact | No |
| Material quality | Other |
| Material | Other |
| Type of fastening | Mounting with claw and screw |
| Number of rockers | 2 |
| RAL-number (similar) | 0 |
| Transparent | No |
| Suitable for degree of protection (IP) | IP20 |
| Number of contacts as change-over contact | 0 |
| Device width | 71 mm |
| Device height | 71 mm |
| Device depth | 37 mm |
| Number of modules (module system) | 0 |
| Min. depth of built-in installation box | 0 mm |
| Number of revolving contacts | 0 |
| Anti-bacterial treatment | No |
Downloads
Description
Schneider Electric Merten inserts MTN3059-0000 is a switch with 1 rocker. This is a 1 pole 1 way switch. 250V is the rated operational voltage. And its rated current is 10AX. And the switching current is no more than 10 A. The fixing mode of this device is by screws and claws. Its matching mounting box can be recessed into the surface of the wall with flush type. The IP rating of this device is IP20. Being made of metal, plastic material, this switch is quite reliable and resistant. Being environmentally friendly, this switch is a green premium product too. And it is mercury free This switch is SVHC (substances of very high concern) free too. Besides it is halogen free halogen free, which is good for your health. Merten inserts can be used in any kind of CEE60 installation, with help of surface boxes and IP 44 solutions all applications.
