Distribution box rubber mobile SCHREMS BV 2x32/5 4x16/5 6xSSD GS63/5 Ea IP54

Order only Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	Distribution box rubber mobile SCHREMS BV 2x32/5 4x16/5 6xSSD GS63/5 Ea IP54
Brand	PCE
Harmonized System Code	8537 1098 00
ETIM	EC000379
Handling	Portable
Degree of protection (IP)	IP54

Packing details

Packing level 1

9003399999062

Other Technical data

Colour	Black
Width	400 mm
Height	255 mm
Depth	300 mm
Number of socket outlets with protective contact (type F)	6
Protection	Overcurrent switch
Housing material	Rubber
Earth leakage switch	Earth leakage switch with IFN 30 mA (standard)
CEE socket outlet 16 A	4x16A5p400V
CEE socket outlet 32 A	2x32A5p400V
Power supply/connection possibility	Built-up plug
Number of miniature circuit breakers	6
Type of mains connection	CEE 63 A

Downloads

Product data sheet

Description

Distribution box, mobile, solid rubber, series SCHREMS IP54 255x400x300
1xhandle on the top, 2xfeet on the bottom (stackable)
1xCEE-flanged plug 63A 5p 400V
2xCEE-socket 32A 5p 400V fused with 1xMCB 32A 3p C
4xCEE-socket 16A 5p 400V fused with 2xMCB 16A 3p C
6xsocket (DIN49440) 16A 250V IP54 fused with 3xMCB 16A 1p C
1xRCD 63A/4/0.03A (TYP A 63AT) over all outlets
MCBs and RCD are brand PCE VDE
Distribution box is ready wired for connection
