Distribution box plastic mobile ISCHL MV 3x16/5 6xSSD 2m5G2.5St16 H07 IP44

Order only Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	Distribution box plastic mobile ISCHL MV 3x16/5 6xSSD 2m5G2.5St16 H07 IP44
Brand	PCE
Harmonized System Code	8536 6990 00
ETIM	EC000379
Handling	Portable
Degree of protection (IP)	IP44

Packing details

Packing level 1

9003399391484

Other Technical data

Colour	Black
Width	300 mm
Height	200 mm
Depth	200 mm
Number of socket outlets with protective contact (type F)	6
Cable length	2 m
Protection	None
Housing material	Plastic
CEE socket outlet 16 A	3x16A5p400V
Power supply/connection possibility	Feeder cable with plug
Type of mains connection	CEE 16 A

Downloads

Product data sheet

Description

thermoplastic mobile distribution box series ISCHL IP44 200x300x200 0TE
2m cable H07RN-F 5G2.5mm2 black with plug 16A 5p 400V
3xCEE-socket 16A 5p 400V protected with pre-fuse of supply chain
6xSK-socket 16A 250V IP54 protected with pre-fuse of supply chain
distribution box is ready wired for using
