DEHNmid MV arrester Ur: 3kV In: 10kA line disch. class 1 normal creepa

Order only Not Available
Estimate delivery time to our warehouse: By request

Technical Information

Item condition New
Manufacture name DEHNmid MV arrester Ur: 3kV In: 10kA line disch. class 1 normal creepa
Brand Dehn
Country of origin* DE
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code 8535 4000 00
ETIM EC002676
Model With screen
Application Exterior area
Rated voltage AC 3 kV
Creepage path 143 mm

Packing details

Packing level 1 4013364102767, 4013364102767

Other Technical data

Height 92 mm
Continuous voltage AC 2.4 kV

Downloads

Product data sheet Circuit diagram

Description

DEHNmid medium-voltage arrester for protecting transformers, switchgear installations and transmission lines against atmospheric and switching overvoltage as per IEC / EN 60099-4. High-temperature vulcanised silicone housing for outdoor use prevents the formation of water and pollution layers. Long service life thanks to powerful metal oxide varistors.
