VORT HRW 30 MONO EVO HCS

Order only

Price (excl. VAT):

356,39 €

This price is valid until 31.12.26

EAN: 8010300124360

MPN: 12436

Package: 1

Estimate delivery time to our warehouse: 3-6 weeks

Technical Information

Item condition	New
Manufacture name	VORT HRW 30 MONO EVO HCS
Brand	VORTICE
Categories	Raumventilatoren
Harmonized System Code	8415 8300 00
ETIM	EC010004
Width	231 mm
Height	200 mm
Depth	260 mm
With movement sensor	No
Connection	Duct end
Energy efficiency class	A
Suitable for movement sensor	No
Housing material	Plastic
Type of motor	Electronically commutated (EC)
Electrical connection	Terminals
Operation by app	No
With internal carbon dioxide (CO2) sensor	Yes
With pressure sensor	No
With external carbon dioxide (CO2) sensor	No
Suitable for (extra) carbon dioxide (CO2) sensor	No
With internal humidity (RH) sensor	Yes
With external humidity (RH) sensor	No
Suitable for (extra) humidity (RH) sensor	No
Suitable for (extra) pressure sensor	No
With wired control unit	No
Suitable for wired control unit	No
With zone controller	No
Suitable for zone controller	No
Max. air volume at 50 Pa	24 m³/h
Max. air volume at 100 Pa	8 m³/h
Max. air volume at 150 Pa	0 m³/h
Max. air volume at 200 Pa	0 m³/h
Max. air volume at 250 Pa	0 m³/h
Max. air volume at 300 Pa	0 m³/h
Type of speed control	Other
Nominal duct diameter	100 mm
With wireless remote control	Yes
Number of suction connections	1
Rear connection	Yes
Power input according to EPN standard	0.004 kW
Suitable for wireless remote control	Yes
Suitable for requirement-controlled ventilation	Yes

Packing level 1

8010300124360
