RAIL MAVISTRUT 41x41D LG3030 HDG
Order only
Price (excl. VAT):
402,27 €
EAN: 3660612247834
MPN: MV68255
Package: 1
Pallet: 48
Estimate delivery time to our warehouse: 4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | RAIL MAVISTRUT 41x41D LG3030 HDG |
| Brand | GEWISS |
| Categories |
Hutschienen
|
| Harmonized System Code | 7216 9110 00 |
| ETIM | EC000386 |
| Width | 41 mm |
| Model | Double profile |
| Height | 82 mm |
| Material thickness | 2.5 mm |
| With toothing | Yes |
| Length | 3030 mm |
| Type of perforation | 3 sides punched |
| Profile shape | C-profile |
| Slit width | 30 mm |
| Hole width | 13 mm |
Packing details
| Packing level 1 | 3660612247834, 3660612247834 |
| Packing level 2 | 3660612247834 |
Other Technical data
| Colour | Zinc |
| RAL-number | 0 |
| Surface protection | Hot-dip galvanized |
| Weight | 13.734 kg |
| Material quality | Other |
| Material | Steel |
| Load bearing capacity | 0 kN |
| Snap-off | No |
| Suitable for circuit integrity | No |
| Moment of resistance Wy | 0 cm³ |
| Moment of resistance Wz | 0 cm³ |
| Area moment of inertia Iy | 0 cm4 |
| Area of inertia Iz | 0 cm4 |
| Layer thickness surface protection | 45 µm |
Description
SP Range Supports and accessories - The GEWISS cable trunking system is completed by the range of installation supports for walls and ceilings, with universal connections, for quick installation and system reliability.
