IRET INVERTER 8 M
Order only
Price (excl. VAT):
1 543,52 €
EAN: 8010300128214
MPN: 12821
Package: 1
Estimate delivery time to our warehouse: 3-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | IRET INVERTER 8 M |
| Brand | VORTICE |
| Categories |
Frequenzumrichter bis 1 kV
|
| Harmonized System Code | 8535 3010 00 |
| ETIM | EC001857 |
| Mains voltage | 208-277 V |
| Mains frequency | 50/60 Hz |
| Number of phases input | 1 |
| Relative symmetric net frequency tolerance | 250 % |
Packing details
| Packing level 1 | 8010300128214 |
Other Technical data
| Width | 240 mm |
| Height | 302 mm |
| Depth | 195.5 mm |
| With control element | No |
| Number of digital inputs | 1 |
| Number of analogue inputs | 1 |
| Supporting protocol for LON | No |
| With optical interface | No |
| Supporting protocol for TCP/IP | No |
| Supporting protocol for ASI | No |
| Supporting protocol for PROFIBUS | No |
| Supporting protocol for CAN | No |
| Supporting protocol for INTERBUS | No |
| Supporting protocol for KNX | No |
| Supporting protocol for Modbus | No |
| Supporting protocol for Data-Highway | No |
| Supporting protocol for DeviceNet | No |
| Supporting protocol for SUCONET | No |
| Supporting protocol for other bus systems | No |
| Degree of protection (IP) | IP54 |
| With PC connection | No |
| Supporting protocol for SERCOS | No |
| Supporting protocol for INTERBUS-Safety | No |
| 4-quadrant operation possible | No |
| Type of converter | Other |
| Number of phases output | 3 |
| Integrated breaking resistance | No |
| Application in industrial area permitted | Yes |
| Application in domestic- and commercial area permitted | Yes |
| Max. output frequency | 60 Hz |
| Supporting protocol for AS-Interface Safety at Work | No |
| Supporting protocol for DeviceNet Safety | No |
| Supporting protocol for EtherNet/IP | No |
| Supporting protocol for Foundation Fieldbus | No |
| Supporting protocol for PROFINET CBA | No |
| Supporting protocol for PROFINET IO | No |
| Supporting protocol for PROFIsafe | No |
| Supporting protocol for SafetyBUS p | No |
| Max. output voltage | 277 V |
| Supporting protocol for BACnet | No |
