Ethernet-Netzwerk-Switch EtherDevice EDS 208
Order only
Price (excl. VAT):
206,78 €
EAN: 4250184120544
MPN: 110196
Package: 1
Estimate delivery time to our warehouse: 4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | EtherDevice Switch EDS 208 |
| Brand | METZ CONNECT |
| Categories |
Netzwerk-Switches
|
| Country of origin* | TW |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8471 8000 00 |
| ETIM | EC000734 |
| Ethernet | Yes |
| Number of ports 10/100 Mbps RJ45 | 8 |
| Number of ports 10/100/1000 Mbps RJ45 | 0 |
| Number of ports 1000 Mbps Mini GBIC | 0 |
| Layer 3 | No |
| Manageable | No |
| Degree of protection (IP) | IP30 |
| Number of ports PoE | 0 |
Packing details
| Packing level 1 | 4250184120544, 4250184120544 |
Other Technical data
| Mounting method | DIN rail (top hat rail) |
| Width | 40 mm |
| Height | 109 mm |
| Depth | 95 mm |
| Number of ports 100 Mbps SC | 0 |
| Number of ports 1000 Mbps RJ45 | 0 |
| Number of ports 100 Mbps ST | 0 |
| Number of ports 1000 Mbps SC (SX) | 0 |
| Number of ports 1000 Mbps SC (LX) | 0 |
| Number of ports 10/100 Mbps M12 | 0 |
| Number of ports 1000 Mbps GBIC | 0 |
| Number of combination-ports RJ45/Mini GBIC | 0 |
| Layer 2 | No |
| Number of other ports | 0 |
| Number of ports 100/1000 Mbps Mini GBIC | 0 |
| Number of ports 10 Gbps Mini GBIC | 0 |
| Number of ports 100 Mbps POF | 0 |
| Number of ports 1000 Mbps POF | 0 |
| Number of ports 40 Gbps Mini GBIC | 0 |
| Number of ports 100 Gbps Mini GBIC | 0 |
| Number of ports 10 Gbps RJ45 | 0 |
| Compatible with Grade2TV according to XP-C 90-483 | No |
| Compatible with Grade3TV according to XP-C 90-483 | No |
Description
The industrial Ethernet switch EDS208 is an entry-level switch supporting IEEE 802.3/802.3u/802.3x with 10/100M, full/half duplex, MDI/MDIX auto-sensing. Switches of the EDS208 series can be easily and conveniently mounted on and dismounted from a standard top hat rail., Variants:EDS208: 8 x 10/100BaseT(X) RJ45EDS208-M-SC: 7 x 10/100BaseT(X) RJ451 x 100BaseFX multi-mode SC connector, 8 ports with 10/100BaseT(X) RJ45 or 7 ports with 10/100BaseT(X) RJ45 and 1 port100BaseFX multi-mode SC connector, Supports IEEE 802.3/802.3u/802.3x, Powerful network switch technology, Protected against broadcast storm, Store and forward switching mode
