CS-MCB-500V 20A C 2P-MCCB
Order only
EAN: 8426487583812
MPN: 0700130
Package: 1
Price (excl. VAT)
124,38 €
per unit
MOQ: 6
EDT to our warehouse: By request
Price valid until 01.03.27 or while in stock
Technical Information
| Item condition | New |
| Manufacture name | CS-MCB-500V 20A C 2P-MCCB |
| Brand | CRADY |
| Categories |
Circuit breakers 20A
|
| Country of origin* | CN |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| ETIM | EC000042 |
| Rated current | 20 A |
| Rated voltage | 500 V |
| Release characteristic | C |
| Width in number of modular spacings | 2 |
| Number of poles (total) | 2 |
Packing details
| Packing level 1 | 8426487583812 |
Other Technical data
| Voltage type | DC |
| Built-in depth | 18 mm |
| Frequency | - Hz |
| Rated insulation voltage Ui | 1000 V |
| Over voltage category | 3 |
| Pollution degree | 3 |
| Explosion-proof | No |
| Degree of protection (IP) | IP40 |
| Number of protected poles | 2 |
| Concurrently switching neutral conductor | No |
| Connectable conductor cross section solid-core | - mm² |
| Connectable conductor cross section multi-wired | 2.5-35 mm² |
| Ambient temperature during operating | -30-70 °C |
| Flush-mounted installation | No |
| Additional equipment possible | No |
| Rated impulse withstand voltage Uimp | 6 kV |
Downloads
Description
Interruptor automático CS-MCB-500V 20A C 2P
