CS-MCB-500V 16A C 2P-MCCB
Order only
Minimal order quantity: 6
Price (excl. VAT):
123,435 €
Subtotal: 740,61 €
MOQ: 6
EAN: 8426487583805
MPN: 0700129
Package: 1
Estimate delivery time at our warehouse (approx.):
By request
Technical Information
| Item condition | New |
| Manufacture name | CS-MCB-500V 16A C 2P-MCCB |
| Brand | CRADY |
| Categories |
Circuit breakers 16A
|
| Country of origin* | CN |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8538 9019 00 |
| Rated current | 16 A |
| Rated voltage | 500 V |
| Release characteristic | C |
| Width in number of modular spacings | 2 |
| Number of poles (total) | 2 |
Packing details
| Packing level 1 | 8426487583805 |
Other Technical data
| Voltage type | DC |
| Built-in depth | 18 mm |
| Frequency | - Hz |
| Rated insulation voltage Ui | 1000 V |
| Over voltage category | 3 |
| Pollution degree | 3 |
| Explosion-proof | No |
| Degree of protection (IP) | IP40 |
| Number of protected poles | 2 |
| Concurrently switching neutral conductor | No |
| Connectable conductor cross section solid-core | - mm² |
| Connectable conductor cross section multi-wired | 2.5-35 mm² |
| Ambient temperature during operating | -30-70 °C |
| Flush-mounted installation | No |
| Additional equipment possible | No |
| Rated impulse withstand voltage Uimp | 6 kV |
Downloads
Description
Interruptor automático CS-MCB-500V 16A C 2P
