M22-AFK03SMC10 Combination of contact element and self-monitoring contact element M22-K01SMC10, M22-A mounting adapter, and M22-XSMC signaling contact actuator., 3 N
Order only
Price (excl. VAT):
21,26 €
EAN: 4015081759637
MPN: 180794
Package: 1
Estimate delivery time at our warehouse (approx.):
1-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | M22-AFK03SMC10 Combination of contact element and self-monitoring contact element M22-K01SMC10, M22-A mounting adapter, and M22-XSMC signaling contact actuator., 3 N |
| Brand | EATON |
| Categories |
Signal & Control Modules
|
| Country of origin* | DE |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8536 5080 00 |
| Mounting method | Front fastening |
| Model | Top mounting |
| Rated operation current Ie at AC-15, 230 V | 1.5 A |
| Type of electric connection | Spring clamp connection |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 1 |
| Number of contacts as change-over contact | 0 |
Packing details
| Packing level 1 | 4015081759637 |
Other Technical data
| Lamp holder | None |
| Number of fault-signal switches | 0 |
Description
Contact element, Connection technique: Cage Clamp, Fixing: Front fixing, Description: Combination of contact element and self-monitoring contact element M22-K01SMC10, M22-A mounting adapter, and M22-XSMC signaling contact actuator., The N/O in the self-monitoring contact element is actuated when mounted with M22-XSMC., Cage Clamp is a registered trademark of Wago Kontakttechnik GmbH/Minden, Germany, Contacts N/C = Normally closed: 3 NC, Contacts Notes: = safety function, by positive opening to IEC/EN 60947-5-1, Actuator travel and actuation force as per DIN EN 60947-5-1, K.5.4.1: mm 5.5, Maximum travel: mm 5.8 , Minimum force for positive opening: N 60, Degree of Protection: IP20, Connection to SmartWire-DT: no, Standards: IEC 60947-5-1
