circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 320 A rating magnetic MA trip unit, 3P 3d

In stock: No Vendor stock: No Minimal order quantity: 1

Price (excl. VAT):

588,95 €

This price is valid until 31.12.25

EAN: 3606480249488

MPN: LV540550

Package: 1

Estimate delivery time at our warehouse (approx.): By request

Technical Information

Item condition	New
Manufacture name	circuit breaker EasyPact CVS400F, 36 kA at 415 VAC, 320 A rating magnetic MA trip unit, 3P 3d
Brand	Schneider Electric
Categories	Motor protection circuit-breakers
Harmonized System Code	8536 2090 00
Rated permanent current Iu	400 A
Number of poles	3
Rated operating voltage	220-440 V
Degree of protection (IP)	IP40
Rated short-circuit breaking capacity lcu at 400 V, AC	36 kA
Adjustment range undelayed short-circuit release	1920-4160 A

Packing details

Packing level 1

3606480249488

Other Technical data

Width	140 mm
Height	255 mm
Depth	110 mm
Rated operation power at AC-3, 400 V	0 kW
With integrated auxiliary switch	Yes
With integrated under voltage release	Yes
With thermal protection	No
Type of electrical connection of main circuit	Screw connection
Type of control element	Other
Switch off technique	Magnetic
Rated operation power at AC-3, 230 V	0 kW
Phase failure sensitive	No
Device construction	Built-in device fixed built-in technique

Downloads

ECOP (Environmental Code of Practice) Declaration EPD (Environmental Product Declaration) Technical manual Instructions for use Others Mounting instruction

Description

This device is a rated current 320A circuit breaker from EasyPact CVS400F. The rated breaking capacity(Ics) is 36kA at 415VAC,and complete range with Ics=100%Icu. The version of breaker is 3poles frame with detection on 3poles, also accompanied MA trip unit for magnetic protection. It is conformed to standard IEC60947-2 for circuit breakers part. This device is certified for operation in pollution degree III environment as defined IEC60947-1& IEC60664-1, and respected for RoHs requirement as european environment directive EC/2002/95. It can be mounted by blackplate or Din rail,also through the door of class II switchboard without downgrading switchboard insulation. The front of toggle offers IP40 protection, but when it is equiped extended rotary handle inside the switchboard, additional IP54 protection degree for extended rotary handle. This series have slots for electrical auxiliaries(MN/MX/OF/SD),depending on the type of trip unit if rotary handle installed. The fixed dimension is 140mm width.255mm height,110mm depth,
