CID-B40300-4 - RESIDUAL CURRENT CIRCUIT BREAKER

In stock: No Vendor stock: No Minimal order quantity: 3

Price (excl. VAT):

Price by request

This price is valid while stock lasts

Subtotal: 0,00 € MOQ: 3

EAN: 8426487598007

MPN: 0135067

Package: 1

Estimate delivery time at our warehouse (approx.): By request

Technical Information

Item condition	New
Manufacture name	CID-B40300-4 - RESIDUAL CURRENT CIRCUIT BREAKER
Brand	CRADY
Categories	RCCB - (Residual Current Breakers)
Country of origin	CN
Harmonized System Code	8536 1050 90
Mounting method	DIN rail
Rated current	40 A
Rated voltage	400 V
Number of poles	4
Rated fault current	0.3 A
Leakage current type	B
Degree of protection (IP)	IP20

Packing level 1

8426487598007

Voltage type	AC
Built-in depth	74 mm
Rated insulation voltage Ui	500 V
Selective protection	No
Surge current capacity	10 kA
Pollution degree	2
Width in number of modular spacings	4
Short-time delayed tripping	No
Explosion-proof	No
Frequency	50/60 Hz
Connectable conductor cross section solid-core	0-25 mm²
Connectable conductor cross section multi-wired	0-25 mm²
With interlocking device	No
Ambient temperature during operating	-25-40 °C
Additional equipment possible	No
Rated impulse withstand voltage Uimp	1 kV

Declaration DOC CE (Declaration of conformity CE) Product data sheet Instructions for use

Interruptor para protección diferencial, clase B, 4 polos, 40A, sensibilidad 300 mA
