CID-A2530-4 RESIDUAL CURRENT CIRCUIT BREAKER
In stock: No
Vendor stock: No
Minimal order quantity: 3
Price (excl. VAT):
Price by request
Subtotal: 0,00 €
MOQ: 3
EAN: 8426487587452
MPN: 0134944
Package: 1
Estimate delivery time at our warehouse (approx.):
By request
Technical Information
| Item condition | New |
| Manufacture name | CID-A2530-4 RESIDUAL CURRENT CIRCUIT BREAKER |
| Brand | CRADY |
| Categories |
RCCB - (Residual Current Breakers)
|
| Country of origin | CN |
| Mounting method | DIN rail |
| Rated current | 25 A |
| Rated voltage | 400 V |
| Number of poles | 4 |
| Leakage current type | A |
| Degree of protection (IP) | IP20 |
Packing details
| Packing level 1 | 8426487587452 |
Other Technical data
| Built-in depth | 60 mm |
| Selective protection | No |
| Short-circuit breaking capacity (Icw) | 10 kA |
| Surge current capacity | 10 kA |
| Width in number of modular spacings | 4 |
| Short-time delayed tripping | No |
| Explosion-proof | No |
| Frequency | 50/60 Hz |
| Connectable conductor cross section solid-core | 4 mm² |
| Connectable conductor cross section multi-wired | 4 mm² |
| With interlocking device | No |
| Ambient temperature during operating | - °C |
| Additional equipment possible | Yes |
Downloads
Description
Interruptor diferencial RCCB CID-A2530-4 Clase A "CID2
